Flexible and movable acustic booth. The outer frame is made of reinforced aluminum, the wall is made of double-layer aluminum honeycomb panels and double-sided soundproof glass, and the interior is equipped with polyester fiber sound-absorbing panels. The all-aluminum material design makes it meet the fire protection requirements, and is safe and stable. Flame-retardant polyester fiber sound-absorbing panels and nylon carpets make it reach the acoustic environment index. Surface treatment of non-chromatic powder spraying in sound insulation chamber
Product parameters
Product Name | New Portable Soundproof Room Recording Vocal Booth |
Powder | 220V |
Sound insulation | RW+Ctr30dB(±5dB) and RT0.25(±0.1s) |
Product Color | Customizable |
Product Feature | Soundproof,Fresh air,illumination,Powder 220V |
Application | Office / School / Home / Recording / Exhibition Hall / Library / Hospital / airport/meeting/Live/Work/Study/Shopping Mall ect. |
Product Features
New Portable Soundproof Room Recording Vocal Booth
1.Sound Insulation：
Our booth is made of 38mm thick double-layer aluminum honeycomb panel.The surface of the aluminum plate is pasted with high-density damping sound insulation felt to meet the requirements of sound insulation. The interior decoration is matched with acoustic materials to meet the requirements of acoustic environment.Design value:Rw+Ctr30db(+5db)and RT0.25s(+0.1s).
2.Ventilation fan:
We made a multiple sound barrier for the ventilation tunnel to noise of ventilation fan, meanwhile, the sound barrier can also reduce much of the sound transmission.
The air in the booth can be circulated in three minutes, to ensure it won’t be stuffy in the booth.
3.Lighting
Equipped with 4000K daylight color temperature LED lighting system 150LX, it would satisfy the needs normal activities.
In the event of additional power requirements, a backup power supply is readily installed inside the booth.
4.220V Power
Our booth is equipped with 12V-USB power supply and power rated for 100-240V/50-60HZ, comping with common equipment requirements.The three control switches control one lamp and two exhaust fans respectively.
5.Hook and Loop Fasteners
Magic tape band is used for the back side installation of acoustic materials. It is environmentally friendly and tasteless,company with European ROHS standard.
Stable and fast installation facilitates repeated used in the future.
The material and application design if magic tape has successfully constructed a model which is easy to disassemble and assemble several times.
6.Sound insulation tempered glass
Our booth adopts train sound insulation tempered glass, which meets the requirements of sound insulation and meets the safety and stability of installation and use.
7.Nylon carpet
We use custom-made nylon carpet,which only needs one piece carpet for a booth. The embedded installation method ensures the level of the booth floor and is not easy to slide.
At the same time,nylon carpet has good sound absorption performance,which can meets oru requirements for acoustic design.
Scope of application
New Portable Soundproof Room Recording Vocal Booth
Soundproof recording studio soundproof booth for sale Flexible and movable soundproof booth.the interior is equipped with polyester fiber sound-absorbing panels. It has the advantages of fire prevention, safety and stability.
